Register 17: Program Status Register (PSR)
Note: This register is also referred to as xPSR.
The Program Status Register (PSR) has three functions, and the register bits are assigned to the
different functions:
■ Application Program Status Register (APSR), bits 31:27, bits 19:16
■ Execution Program Status Register (EPSR), bits 26:24, 15:10
■ Interrupt Program Status Register (IPSR), bits 7:0
The PSR, IPSR, and EPSR registers can only be accessed in privileged mode; the APSR register
can be accessed in either privileged or unprivileged mode.
APSR contains the current state of the condition flags from previous instruction executions.
EPSR contains the Thumb state bit and the execution state bits for the If-Then (IT) instruction or
the Interruptible-Continuable Instruction (ICI) field for an interrupted load multiple or store multiple
instruction. Attempts to read the EPSR directly through application software using the MSR instruction
always return zero. Attempts to write the EPSR using the MSR instruction in application software
are always ignored. Fault handlers can examine the EPSR value in the stacked PSR to determine
the operation that faulted (see “Exception Entry and Return” on page 120).
IPSR contains the exception type number of the current Interrupt Service Routine (ISR).
These registers can be accessed individually or as a combination of any two or all three registers,
using the register name as an argument to the MSR or MRS instructions. For example, all of the
registers can be read using PSR with the MRS instruction, or APSR only can be written to using
APSR with the MSR instruction. page 92 shows the possible register combinations for the PSR. See
the MRS and MSR instruction descriptions in the Cortex™-M4 instruction set chapter in the ARM®
Cortex™-M4 Devices Generic User Guide (literature number ARM DUI 0553A) for more information
about how to access the program status registers.
Table 2-3. PSR Register Combinations
CombinationTypeRegister
APSR, EPSR, and IPSRRW
a
,
b
PSR
EPSR and IPSRROIEPSR
APSR and IPSRRW
a
IAPSR
APSR and EPSRRW
b
EAPSR
a. The processor ignores writes to the IPSR bits.
b. Reads of the EPSR bits return zero, and the processor ignores writes to these bits.
Program Status Register (PSR)
Type RW, reset 0x0100.0000
16171819202122232425262728293031
GEreservedTHUMBICI / ITQVCZN
RWRWRWRWRORORORORORORORWRWRWRWRWType
0000000010000000Reset
0123456789101112131415
ISRNUMreservedICI / IT
ROROROROROROROROROROROROROROROROType
0000000000000000Reset
June 18, 201492
Texas Instruments-Production Data
The Cortex-M4F Processor
