Register 68: Watchdog Timer Software Reset (SRWD), offset 0x500
The SRWD register provides software the capability to reset the available watchdog modules.
A peripheral is reset by software using a simple two-step process:
1. Software sets a bit (or bits) in the SRWD register. While the SRWD bit is 1, the peripheral is
held in reset.
2. Software completes the reset process by clearing the SRWD bit.
There may be latency from the clearing of the SRWD bit to when the peripheral is ready for use.
Software should check the corresponding PRWD bit to verify that the Watchdog Timer Module
registers are ready to be accessed.
Important: This register should be used to reset the watchdog modules.
Watchdog Timer Software Reset (SRWD)
Base 0x400F.E000
Offset 0x500
Type RW, reset 0x0000.0000
16171819202122232425262728293031
reserved
ROROROROROROROROROROROROROROROROType
0000000000000000Reset
0123456789101112131415
R0R1reserved
RWRWROROROROROROROROROROROROROROType
0000000000000000Reset
DescriptionResetTypeNameBit/Field
Software should not rely on the value of a reserved bit. To provide
compatibility with future products, the value of a reserved bit should be
preserved across a read-modify-write operation.
0ROreserved31:2
Watchdog Timer 1 Software Reset
DescriptionValue
Watchdog module 1 is not reset.0
Watchdog module 1 is reset.1
0RWR11
Watchdog Timer 0 Software Reset
DescriptionValue
Watchdog module 0 is not reset.0
Watchdog module 0 is reset.1
0RWR00
June 18, 2014354
