Texas Instruments TM4C1294NCPDT User Manual

Register 101: Pulse Width Modulator Run Mode Clock Gating Control
(RCGCPWM), offset 0x640
The RCGCPWM register provides software the capability to enable and disable the PWM modules
in Run mode. When enabled, a module is provided a clock and accesses to module registers are
allowed. When disabled, the clock is disabled to save power and accesses to module registers
generate a bus fault.
Important: This register should be used to control the clocking for the PWM modules.
Pulse Width Modulator Run Mode Clock Gating Control (RCGCPWM)
Base 0x400F.E000
Offset 0x640
Type RW, reset 0x0000.0000
16171819202122232425262728293031
reserved
ROROROROROROROROROROROROROROROROType
0000000000000000Reset
0123456789101112131415
R0reserved
RWROROROROROROROROROROROROROROROType
0000000000000000Reset
DescriptionResetTypeNameBit/Field
Software should not rely on the value of a reserved bit. To provide
compatibility with future products, the value of a reserved bit should be
preserved across a read-modify-write operation.
0ROreserved31:1
PWM Module 0 Run Mode Clock Gating Control
DescriptionValue
PWM module 0 is disabled.0
Enable and provide a clock to PWM module 0 in Run mode.1
0RWR00
June 18, 2014398
Texas Instruments-Production Data
System Control
