26.5 Possible Pin Assignments for Alternate Functions
Table 26-6. Possible Pin Assignments for Alternate Functions
GPIO FunctionAlternate Function# of Possible Assignments
PE3AIN0
one
PE2AIN1
PB4AIN10
PB5AIN11
PD3AIN12
PD2AIN13
PD1AIN14
PD0AIN15
PK0AIN16
PK1AIN17
PK2AIN18
PK3AIN19
PE1AIN2
PE0AIN3
PD7AIN4
PD6AIN5
PD5AIN6
PD4AIN7
PE5AIN8
PE4AIN9
PC6C0+
PC7C0-
PC5C1+
PC4C1-
PP0C2+
PP1C2-
PD2C2o
PA0CAN0Rx
PA1CAN0Tx
PB0CAN1Rx
PB1CAN1Tx
PQ4DIVSCLK
PG1EPI0S10
PG0EPI0S11
PM3EPI0S12
PM2EPI0S13
PM1EPI0S14
PM0EPI0S15
PL0EPI0S16
