Register 17: ADC Sample Sequence Result FIFO 0 (ADCSSFIFO0), offset 0x048
Register 18: ADC Sample Sequence Result FIFO 1 (ADCSSFIFO1), offset 0x068
Register 19: ADC Sample Sequence Result FIFO 2 (ADCSSFIFO2), offset 0x088
Register 20: ADC Sample Sequence Result FIFO 3 (ADCSSFIFO3), offset
0x0A8
Important: This register is read-sensitive. See the register description for details.
This register contains the conversion results for samples collected with the sample sequencer (the
ADCSSFIFO0 register is used for Sample Sequencer 0, ADCSSFIFO1 for Sequencer 1,
ADCSSFIFO2 for Sequencer 2, and ADCSSFIFO3 for Sequencer 3). Reads of this register return
conversion result data in the order sample 0, sample 1, and so on, until the FIFO is empty. If the
FIFO is not properly handled by software, overflow and underflow conditions are registered in the
ADCOSTAT and ADCUSTAT registers.
ADC Sample Sequence Result FIFO n (ADCSSFIFOn)
ADC0 base: 0x4003.8000
ADC1 base: 0x4003.9000
Offset 0x048
Type RO, reset -
16171819202122232425262728293031
reserved
ROROROROROROROROROROROROROROROROType
0000000000000000Reset
0123456789101112131415
DATAreserved
ROROROROROROROROROROROROROROROROType
------------0000Reset
DescriptionResetTypeNameBit/Field
Software should not rely on the value of a reserved bit. To provide
compatibility with future products, the value of a reserved bit should be
preserved across a read-modify-write operation.
0x0000.0ROreserved31:12
Conversion Result Data-RODATA11:0
June 18, 20141118
Texas Instruments-Production Data
Analog-to-Digital Converter (ADC)
