Register 20: Interrupt 0-31 Active Bit (ACTIVE0), offset 0x300
Register 21: Interrupt 32-63 Active Bit (ACTIVE1), offset 0x304
Register 22: Interrupt 64-95 Active Bit (ACTIVE2), offset 0x308
Register 23: Interrupt 96-127 Active Bit (ACTIVE3), offset 0x30C
Note: This register can only be accessed from privileged mode.
The UNPENDn registers indicate which interrupts are active. Bit 0 of ACTIVE0 corresponds to
Interrupt 0; bit 31 corresponds to Interrupt 31. Bit 0 of ACTIVE1 corresponds to Interrupt 32; bit 31
corresponds to Interrupt 63. Bit 0 of ACTIVE2 corresponds to Interrupt 64; bit 31 corresponds to
Interrupt 95. Bit 0 of ACTIVE3 corresponds to Interrupt 96; bit 17 corresponds to Interrupt 113.
See Table 2-9 on page 116 for interrupt assignments.
Caution – Do not manually set or clear the bits in this register.
Interrupt 0-31 Active Bit (ACTIVE0)
Base 0xE000.E000
Offset 0x300
Type RO, reset 0x0000.0000
16171819202122232425262728293031
INT
ROROROROROROROROROROROROROROROROType
0000000000000000Reset
0123456789101112131415
INT
ROROROROROROROROROROROROROROROROType
0000000000000000Reset
DescriptionResetTypeNameBit/Field
Interrupt Active
DescriptionValue
The corresponding interrupt is not active.0
The corresponding interrupt is active, or active and pending.1
0x0000.0000ROINT31:0
June 18, 2014158
Texas Instruments-Production Data
Cortex-M4 Peripherals
