Texas Instruments TM4C1294NCPDT User Manual

Register 47: ADC Digital Comparator Reset Initial Conditions (ADCDCRIC),
offset 0xD00
This register provides the ability to reset any of the digital comparator interrupt or trigger functions
back to their initial conditions. Resetting these functions ensures that the data that is being used by
the interrupt and trigger functions in the digital comparator unit is not stale.
ADC Digital Comparator Reset Initial Conditions (ADCDCRIC)
ADC0 base: 0x4003.8000
ADC1 base: 0x4003.9000
Offset 0xD00
Type WO, reset 0x0000.0000
16171819202122232425262728293031
DCTRIG0DCTRIG1DCTRIG2DCTRIG3DCTRIG4DCTRIG5DCTRIG6DCTRIG7reserved
WOWOWOWOWOWOWOWOROROROROROROROROType
0000000000000000Reset
0123456789101112131415
DCINT0DCINT1DCINT2DCINT3DCINT4DCINT5DCINT6DCINT7reserved
WOWOWOWOWOWOWOWOROROROROROROROROType
0000000000000000Reset
DescriptionResetTypeNameBit/Field
Software should not rely on the value of a reserved bit. To provide
compatibility with future products, the value of a reserved bit should be
preserved across a read-modify-write operation.
0x00ROreserved31:24
Digital Comparator Trigger 7
DescriptionValue
No effect.0
Resets the Digital Comparator 7 trigger unit to its initial
conditions.
1
When the trigger has been cleared, this bit is automatically cleared.
Because the digital comparators use the current and previous ADC
conversion values to determine when to assert the trigger, it is important
to reset the digital comparator to initial conditions when starting a new
sequence so that stale data is not used. After setting this bit, software
should wait until the bit clears before continuing.
0WODCTRIG723
Digital Comparator Trigger 6
DescriptionValue
No effect.0
Resets the Digital Comparator 6 trigger unit to its initial
conditions.
1
When the trigger has been cleared, this bit is automatically cleared.
Because the digital comparators use the current and previous ADC
conversion values to determine when to assert the trigger, it is important
to reset the digital comparator to initial conditions when starting a new
sequence so that stale data is not used.
0WODCTRIG622
June 18, 20141148
Texas Instruments-Production Data
Analog-to-Digital Converter (ADC)
