Register 3: QEI Position (QEIPOS), offset 0x008
This register contains the current value of the position integrator. The value is updated by the status
of the QEI phase inputs and can be set to a specific value by writing to it.
QEI Position (QEIPOS)
QEI0 base: 0x4002.C000
Offset 0x008
Type RW, reset 0x0000.0000
16171819202122232425262728293031
POSITION
RWRWRWRWRWRWRWRWRWRWRWRWRWRWRWRWType
0000000000000000Reset
0123456789101112131415
POSITION
RWRWRWRWRWRWRWRWRWRWRWRWRWRWRWRWType
0000000000000000Reset
DescriptionResetTypeNameBit/Field
Current Position Integrator Value
The current value of the position integrator.
0x0000.0000RWPOSITION31:0
1759June 18, 2014
Texas Instruments-Production Data
