Register 4: QEI Maximum Position (QEIMAXPOS), offset 0x00C
This register contains the maximum value of the position integrator. When moving forward, the
position register resets to zero when it increments past this value. When moving in reverse, the
position register resets to this value when it decrements from zero.
QEI Maximum Position (QEIMAXPOS)
QEI0 base: 0x4002.C000
Offset 0x00C
Type RW, reset 0x0000.0000
16171819202122232425262728293031
MAXPOS
RWRWRWRWRWRWRWRWRWRWRWRWRWRWRWRWType
0000000000000000Reset
0123456789101112131415
MAXPOS
RWRWRWRWRWRWRWRWRWRWRWRWRWRWRWRWType
0000000000000000Reset
DescriptionResetTypeNameBit/Field
Maximum Position Integrator Value
The maximum value of the position integrator.
0x0000.0000RWMAXPOS31:0
June 18, 20141760
Texas Instruments-Production Data
Quadrature Encoder Interface (QEI)
