Table 9-13. μDMA Register Map (continued)
See
page
DescriptionResetTypeNameOffset
721DMA Channel Enable Set0x0000.0000RWDMAENASET0x028
722DMA Channel Enable Clear-WODMAENACLR0x02C
723DMA Channel Primary Alternate Set0x0000.0000RWDMAALTSET0x030
724DMA Channel Primary Alternate Clear-WODMAALTCLR0x034
725DMA Channel Priority Set0x0000.0000RWDMAPRIOSET0x038
726DMA Channel Priority Clear-WODMAPRIOCLR0x03C
727DMA Bus Error Clear0x0000.0000RWDMAERRCLR0x04C
728DMA Channel Assignment0x0000.0000RWDMACHASGN0x500
729DMA Channel Map Select 00x0000.0000RWDMACHMAP00x510
730DMA Channel Map Select 10x0000.0000RWDMACHMAP10x514
731DMA Channel Map Select 20x0000.0000RWDMACHMAP20x518
732DMA Channel Map Select 30x0000.0000RWDMACHMAP30x51C
737DMA Peripheral Identification 40x0000.0004RODMAPeriphID40xFD0
733DMA Peripheral Identification 00x0000.0030RODMAPeriphID00xFE0
734DMA Peripheral Identification 10x0000.00B2RODMAPeriphID10xFE4
735DMA Peripheral Identification 20x0000.000BRODMAPeriphID20xFE8
736DMA Peripheral Identification 30x0000.0000RODMAPeriphID30xFEC
738DMA PrimeCell Identification 00x0000.000DRODMAPCellID00xFF0
739DMA PrimeCell Identification 10x0000.00F0RODMAPCellID10xFF4
740DMA PrimeCell Identification 20x0000.0005RODMAPCellID20xFF8
741DMA PrimeCell Identification 30x0000.00B1RODMAPCellID30xFFC
9.5 μDMA Channel Control Structure
The μDMA Channel Control Structure holds the transfer settings for a μDMA channel. Each channel
has two control structures, which are located in a table in system memory. Refer to “Channel
Configuration” on page 683 for an explanation of the Channel Control Table and the Channel Control
Structure.
The channel control structure is one entry in the channel control table. Each channel has a primary
and alternate structure. The primary control structures are located at offsets 0x0, 0x10, 0x20 and
so on. The alternate control structures are located at offsets 0x200, 0x210, 0x220, and so on.
June 18, 2014702
Texas Instruments-Production Data
Micro Direct Memory Access (μDMA)
