Register 54: Pulse Width Modulator Peripheral Present (PPPWM), offset 0x340
The PPPWM register provides software information regarding the PWM modules.
Important: This register should be used to determine which PWM modules are implemented on
this microcontroller.
Pulse Width Modulator Peripheral Present (PPPWM)
Base 0x400F.E000
Offset 0x340
Type RO, reset 0x0000.0001
16171819202122232425262728293031
reserved
ROROROROROROROROROROROROROROROROType
0000000000000000Reset
0123456789101112131415
P0reserved
ROROROROROROROROROROROROROROROROType
1000000000000000Reset
DescriptionResetTypeNameBit/Field
Software should not rely on the value of a reserved bit. To provide
compatibility with future products, the value of a reserved bit should be
preserved across a read-modify-write operation.
0ROreserved31:1
PWM Module 0 Present
DescriptionValue
PWM module 0 is not present.0
PWM module 0 is present.1
0x1ROP00
June 18, 2014340
Texas Instruments-Production Data
System Control
