Texas Instruments TM4C1294NCPDT User Manual

Register 41: 16/32-Bit General-Purpose Timer Peripheral Present (PPTIMER),
offset 0x304
The PPTIMER register provides software information regarding the 16/32-bit general-purpose timer
modules.
Important: This register should be used to determine which timers are implemented on this
microcontroller.
16/32-Bit General-Purpose Timer Peripheral Present (PPTIMER)
Base 0x400F.E000
Offset 0x304
Type RO, reset 0x0000.00FF
16171819202122232425262728293031
reserved
ROROROROROROROROROROROROROROROROType
0000000000000000Reset
0123456789101112131415
P0P1P2P3P4P5P6P7reserved
ROROROROROROROROROROROROROROROROType
1111111100000000Reset
DescriptionResetTypeNameBit/Field
Software should not rely on the value of a reserved bit. To provide
compatibility with future products, the value of a reserved bit should be
preserved across a read-modify-write operation.
0ROreserved31:8
16/32-Bit General-Purpose Timer 7 Present
DescriptionValue
16/32-bit general-purpose timer module 7 is not present.0
16/32-bit general-purpose timer module 7 is present.1
0x1ROP77
16/32-Bit General-Purpose Timer 6 Present
DescriptionValue
16/32-bit general-purpose timer module 6 is not present.0
16/32-bit general-purpose timer module 6 is present.1
0x1ROP66
16/32-Bit General-Purpose Timer 5 Present
DescriptionValue
16/32-bit general-purpose timer module 5 is not present.0
16/32-bit general-purpose timer module 5 is present.1
0x1ROP55
16/32-Bit General-Purpose Timer 4 Present
DescriptionValue
16/32-bit general-purpose timer module 4 is not present.0
16/32-bit general-purpose timer module 4 is present.1
0x1ROP44
321June 18, 2014
Texas Instruments-Production Data
Tiva
™
TM4C1294NCPDT Microcontroller
