Register 14: QSSI Peripheral Identification 5 (SSIPeriphID5), offset 0xFD4
The SSIPeriphIDn registers are hard-coded and the fields within the register determine the reset
value.
QSSI Peripheral Identification 5 (SSIPeriphID5)
QSSI0 base: 0x4000.8000
QSSI1 base: 0x4000.9000
QSSI2 base: 0x4000.A000
QSSI3 base: 0x4000.B000
Offset 0xFD4
Type RO, reset 0x0000.0000
16171819202122232425262728293031
reserved
ROROROROROROROROROROROROROROROROType
0000000000000000Reset
0123456789101112131415
PID5reserved
ROROROROROROROROROROROROROROROROType
0000000000000000Reset
DescriptionResetTypeNameBit/Field
Software should not rely on the value of a reserved bit. To provide
compatibility with future products, the value of a reserved bit should be
preserved across a read-modify-write operation.
0x0000.00ROreserved31:8
QSSI Peripheral ID Register [15:8]
Can be used by software to identify the presence of this peripheral.
0x00ROPID57:0
June 18, 20141264
Texas Instruments-Production Data
Quad Synchronous Serial Interface (QSSI)
