Register 4: ADC Interrupt Status and Clear (ADCISC), offset 0x00C
This register provides the mechanism for clearing sample sequencer interrupt conditions and shows
the status of interrupts generated by the sample sequencers and the digital comparators which have
been sent to the interrupt controller. When read, each bit field is the logical AND of the respective
INR and MASK bits. Sample sequencer interrupts are cleared by writing a 1 to the corresponding
bit position. Digital comparator interrupts are cleared by writing a 1 to the appropriate bits in the
ADCDCISC register. If software is polling the ADCRIS instead of generating interrupts, the sample
sequence INRn bits are still cleared via the ADCISC register, even if the INn bit is not set.
ADC Interrupt Status and Clear (ADCISC)
ADC0 base: 0x4003.8000
ADC1 base: 0x4003.9000
Offset 0x00C
Type RW1C, reset 0x0000.0000
16171819202122232425262728293031
DCINSS0DCINSS1DCINSS2DCINSS3reserved
ROROROROROROROROROROROROROROROROType
0000000000000000Reset
0123456789101112131415
IN0IN1IN2IN3reservedDMAIN0DMAIN1DMAIN2DMAIN3reserved
RW1CRW1CRW1CRW1CRORORORORW1CRW1CRW1CRW1CROROROROType
0000000000000000Reset
DescriptionResetTypeNameBit/Field
Software should not rely on the value of a reserved bit. To provide
compatibility with future products, the value of a reserved bit should be
preserved across a read-modify-write operation.
0x000ROreserved31:20
Digital Comparator Interrupt Status on SS3
DescriptionValue
No interrupt has occurred or the interrupt is masked.0
Both the INRDC bit in the ADCRIS register and the DCONSS3
bit in the ADCIM register are set, providing a level-based
interrupt to the interrupt controller.
1
This bit is cleared by writing a 1 to it. Clearing this bit also clears the
INRDC bit in the ADCRIS register.
0RODCINSS319
Digital Comparator Interrupt Status on SS2
DescriptionValue
No interrupt has occurred or the interrupt is masked.0
Both the INRDC bit in the ADCRIS register and the DCONSS2
bit in the ADCIM register are set, providing a level-based
interrupt to the interrupt controller.
1
This bit is cleared by writing a 1 to it. Clearing this bit also clears the
INRDC bit in the ADCRIS register.
0RODCINSS218
1085June 18, 2014
Texas Instruments-Production Data
Tiva
™
TM4C1294NCPDT Microcontroller
