Texas Instruments TM4C1294NCPDT User Manual

Register 5: Hibernation Interrupt Mask (HIBIM), offset 0x014
This register is the interrupt mask register for the Hibernation module interrupt sources. Each bit in
this register masks the corresponding bit in the Hibernation Raw Interrupt Status (HIBRIS) register.
If a bit is unmasked, the interrupt is sent to the interrupt controller. If the bit is masked, the interrupt
is not sent to the interrupt controller. The WC bit of the HIBIM register may be set before the CLK32EN
bit of the HIBCTL register is set. This allows software to use the WC interrupt trigger to detect when
the RTCOSC clock is stable, which may be in excess of one second. If the WC bit is set before the
CLK32EN has been set, the mask value is not preserved over a hibernate cycle unless the bit is
written a second time.
Note: The WC bit of this register is in the system clock domain such that a write to this bit is
immediate and may be done before the CLK32EN bit is set in the HIBCTL register.
Hibernation Interrupt Mask (HIBIM)
Base 0x400F.C000
Offset 0x014
Type RW, reset 0x0000.0000
16171819202122232425262728293031
reserved
ROROROROROROROROROROROROROROROROType
0000000000000000Reset
0123456789101112131415
RTCALT0reservedLOWBATEXTWWCPADIOWKRSTWKVDDFAILreserved
RWRORWRWRWRWRWRWROROROROROROROROType
0000000000000000Reset
DescriptionResetTypeNameBit/Field
Software should not rely on the value of a reserved bit. To provide
compatibility with future products, the value of a reserved bit should be
preserved across a read-modify-write operation.
0x0000.000ROreserved31:8
VDD Fail Interrupt Mask
DescriptionValue
The VDDFAIL interrupt is suppressed and not sent to the
interrupt controller.
0
An interrupt is sent to the interrupt controller when the VDDFAIL
bit in the HIBRIS register is set.
1
0RWVDDFAIL7
Reset Pad I/O Wake-Up Interrupt Mask
DescriptionValue
The RSTWK interrupt is suppressed and not sent to the interrupt
controller.
0
An interrupt is sent to the interrupt controller when the RSTWK
bit in the HIBRIS register is set.
1
0RWRSTWK6
June 18, 2014562
Texas Instruments-Production Data
Hibernation Module
