Texas Instruments TM4C1294NCPDT User Manual

27.3 Recommended Operating Conditions
The following sections describe the recommended DC operating conditions and GPIO operating
characteristics for the device.
27.3.1 DC Operating Conditions
Table 27-6. Recommended DC Operating Conditions
UnitMaxNomMinParameter NameParameter
V3.633.32.97V
DD
supply voltageV
DD
V3.633.32.97V
DDA
supply voltageV
DDA
a
V1.321.21.14V
DDC
supply voltage, Run modeV
DDC
V0.95-0.85V
DDC
supply voltage, Deep-Sleep modeV
DDCDS
a. To ensure proper operation, V
DDA
must be powered up before V
DD
if sourced from different supplies, or connected to the
same supply as V
DD
. There is not a restriction on order for powering off.
27.3.2 Recommended GPIO Operating Characteristics
Two types of pads are provided on the device:
■ Fast GPIO pads: These pads provide variable, programmable drive strength and optimized
voltage output levels.
■ Slow GPIO pads: These pads provide 2-mA drive strength and are designed to be sensitive to
voltage inputs. The following GPIOs port pins are designed with Slow GPIO Pads:
– PJ1
All other GPIOs have a fast GPIO pad-type.
Note: Port pins PL6 and PL7 operate as Fast GPIO pads, but have 4-mA drive capability only.
GPIO register controls for drive strength, slew rate and open drain have no effect on these
pins. The registers which have no effect are as follows: GPIODR2R, GPIODR4R,
GPIODR8R, GPIODR12R, GPIOSLR, and GPIOODR.
Note: Port pins PM[7:4] operate as Fast GPIO pads but support only 2-, 4-, 6-, and 8-mA drive
capability. 10- and 12-mA drive are not supported. All standard GPIO register controls,
except for the GPIODR12R register, apply to these port pins.
Table 27-7 on page 1820 detail the GPIO operating conditions for these two different pad types.
Table 27-7. Recommended FAST GPIO Pad Operating Conditions
UnitMaxNomMinParameter NameParameter
V4-0.65 * V
DD
Fast GPIO high-level input voltageV
IH
nA300--Fast GPIO high-level input current
a
I
IH
V0.35 * V
DD
-0Fast GPIO low-level input voltageV
IL
nA-200--Fast GPIO low-level input current
a
I
IL
V--0.49Fast GPIO Input HysteresisV
HYS
V--2.4Fast GPIO High-level output voltageV
OH
V0.40--Fast GPIO Low-level output voltageV
OL
June 18, 20141820
Texas Instruments-Production Data
Electrical Characteristics
