Register 29: EPI DMA Transmit Count (EPIDMATXCNT), offset 0x208
This register is used to program the total number of transfers (byte, halfword or word) by the µDMA
to WRFIFO. As each transfer is processed by the EPI, the TXCNT bit field value is decreased by 1.
When TXCNT = 0, the EPI's uDMA request signal is deasserted.
EPI DMA Transmit Count (EPIDMATXCNT)
Base 0x400D.0000
Offset 0x208
Type RW, reset 0x0000.0000
16171819202122232425262728293031
reserved
ROROROROROROROROROROROROROROROROType
0000000000000000Reset
0123456789101112131415
TXCNT
RWRWRWRWRWRWRWRWRWRWRWRWRWRWRWRWType
0000000000000000Reset
DescriptionResetTypeNameBit/Field
Software should not rely on the value of a reserved bit. To provide
compatibility with future products, the value of a reserved bit should be
preserved across a read-modify-write operation.
0x0000ROreserved31:16
DMA Count
This field is used to program the total number of transfers (byte, halfword
or word) from the µDMA to the EPI WRFIFO.
0x0000RWTXCNT15:0
June 18, 2014906
Texas Instruments-Production Data
External Peripheral Interface (EPI)
