Register 30: CAN Transmission Request 1 (CANTXRQ1), offset 0x100
Register 31: CAN Transmission Request 2 (CANTXRQ2), offset 0x104
The CANTXRQ1 and CANTXRQ2 registers hold the TXRQST bits of the 32 message objects. By
reading out these bits, the CPU can check which message object has a transmission request pending.
The TXRQST bit of a specific message object can be changed by three sources: (1) the CPU via the
CANIFnMCTL register, (2) the message handler state machine after the reception of a remote
frame, or (3) the message handler state machine after a successful transmission.
The CANTXRQ1 register contains the TXRQST bits of the first 16 message objects in the message
RAM; the CANTXRQ2 register contains the TXRQST bits of the second 16 message objects.
CAN Transmission Request n (CANTXRQn)
CAN0 base: 0x4004.0000
CAN1 base: 0x4004.1000
Offset 0x100
Type RO, reset 0x0000.0000
16171819202122232425262728293031
reserved
ROROROROROROROROROROROROROROROROType
0000000000000000Reset
0123456789101112131415
TXRQST
ROROROROROROROROROROROROROROROROType
0000000000000000Reset
DescriptionResetTypeNameBit/Field
Software should not rely on the value of a reserved bit. To provide
compatibility with future products, the value of a reserved bit should be
preserved across a read-modify-write operation.
0x0000ROreserved31:16
Transmission Request Bits
DescriptionValue
The corresponding message object is not waiting for
transmission.
0
The transmission of the corresponding message object
is requested and is not yet done.
1
0x0000ROTXRQST15:0
