Register 70: General-Purpose Input/Output Software Reset (SRGPIO), offset
0x508
The SRGPIO register provides software the capability to reset the available GPIO modules.
A peripheral is reset by software using a simple two-step process:
1. Software sets a bit (or bits) in the SRGPIO register. While the SRGPIO bit is 1, the peripheral
is held in reset.
2. Software completes the reset process by clearing the SRGPIO bit.
There may be latency from the clearing of the SRGPIO bit to when the peripheral is ready for use.
Software should check the corresponding PRGPIO bit to verify that the GPIO Module registers are
ready to be accessed.
Important: This register should be used to reset the GPIO modules.
General-Purpose Input/Output Software Reset (SRGPIO)
Base 0x400F.E000
Offset 0x508
Type RW, reset 0x0000.0000
16171819202122232425262728293031
reserved
ROROROROROROROROROROROROROROROROType
0000000000000000Reset
0123456789101112131415
R0R1R2R3R4R5R6R7R8R9R10R11R12R13R14reserved
RWRWRWRWRWRWRWRWRWRWRWRWRWRWRWROType
0000000000000000Reset
DescriptionResetTypeNameBit/Field
Software should not rely on the value of a reserved bit. To provide
compatibility with future products, the value of a reserved bit should be
preserved across a read-modify-write operation.
0ROreserved31:15
GPIO Port Q Software Reset
DescriptionValue
GPIO Port Q is not reset.0
GPIO Port Q is reset.1
0RWR1414
GPIO Port P Software Reset
DescriptionValue
GPIO Port P is not reset.0
GPIO Port P is reset.1
0RWR1313
357June 18, 2014
Texas Instruments-Production Data
Tiva
™
TM4C1294NCPDT Microcontroller
