Register 6: DMA Channel Control Base Pointer (DMACTLBASE), offset 0x008
The DMACTLBASE register must be configured so that the base pointer points to a location in
system memory.
The amount of system memory that must be assigned to the μDMA controller depends on the
number of μDMA channels used and whether the alternate channel control data structure is used.
See “Channel Configuration” on page 683 for details about the Channel Control Table. The base
address must be aligned on a 1024-byte boundary. This register cannot be read when the μDMA
controller is in the reset state.
DMA Channel Control Base Pointer (DMACTLBASE)
Base 0x400F.F000
Offset 0x008
Type RW, reset 0x0000.0000
16171819202122232425262728293031
ADDR
RWRWRWRWRWRWRWRWRWRWRWRWRWRWRWRWType
0000000000000000Reset
0123456789101112131415
reservedADDR
RORORORORORORORORORORWRWRWRWRWRWType
0000000000000000Reset
DescriptionResetTypeNameBit/Field
Channel Control Base Address
This field contains the pointer to the base address of the channel control
table. The base address must be 1024-byte aligned.
0x0000.00RWADDR31:10
Software should not rely on the value of a reserved bit. To provide
compatibility with future products, the value of a reserved bit should be
preserved across a read-modify-write operation.
0x00ROreserved9:0
