Register 16: ADC Sample Sequence Control 0 (ADCSSCTL0), offset 0x044
This register contains the configuration information for each sample for a sequence executed with
a sample sequencer. When configuring a sample sequence, the END bit must be set for the final
sample, whether it be after the first sample, eighth sample, or any sample in between. This register
is 32 bits wide and contains information for eight possible samples.
ADC Sample Sequence Control 0 (ADCSSCTL0)
ADC0 base: 0x4003.8000
ADC1 base: 0x4003.9000
Offset 0x044
Type RW, reset 0x0000.0000
16171819202122232425262728293031
D4END4IE4TS4D5END5IE5TS5D6END6IE6TS6D7END7IE7TS7
RWRWRWRWRWRWRWRWRWRWRWRWRWRWRWRWType
0000000000000000Reset
0123456789101112131415
D0END0IE0TS0D1END1IE1TS1D2END2IE2TS2D3END3IE3TS3
RWRWRWRWRWRWRWRWRWRWRWRWRWRWRWRWType
0000000000000000Reset
DescriptionResetTypeNameBit/Field
8th Sample Temp Sensor Select
DescriptionValue
The input pin specified by the ADCSSMUXn register is read
during the eighth sample of the sample sequence.
0
The temperature sensor is read during the eighth sample of the
sample sequence.
1
0RWTS731
8th Sample Interrupt Enable
DescriptionValue
The raw interrupt is not asserted to the interrupt controller.0
The raw interrupt signal (INR0 bit) is asserted at the end of the
eighth sample's conversion. If the MASK0 bit in the ADCIM
register is set, the interrupt is promoted to the interrupt controller.
1
It is legal to have multiple samples within a sequence generate interrupts.
0RWIE730
8th Sample is End of Sequence
DescriptionValue
Another sample in the sequence is the final sample.0
The eighth sample is the last sample of the sequence.1
It is possible to end the sequence on any sample position. Software
must set an ENDn bit somewhere within the sequence. Samples defined
after the sample containing a set ENDn bit are not requested for
conversion even though the fields may be non-zero.
0RWEND729
1111June 18, 2014
Texas Instruments-Production Data
Tiva
™
TM4C1294NCPDT Microcontroller
