Register 2: CAN Status (CANSTS), offset 0x004
Important: This register is read-sensitive. See the register description for details.
The status register contains information for interrupt servicing such as Bus-Off, error count threshold,
and error types.
The LEC field holds the code that indicates the type of the last error to occur on the CAN bus. This
field is cleared when a message has been transferred (reception or transmission) without error. The
unused error code 0x7 may be written by the CPU to manually set this field to an invalid error so
that it can be checked for a change later.
An error interrupt is generated by the BOFF and EWARN bits, and a status interrupt is generated by
the RXOK, TXOK, and LEC bits, if the corresponding enable bits in the CAN Control (CANCTL)
register are set. A change of the EPASS bit or a write to the RXOK, TXOK, or LEC bits does not
generate an interrupt.
Reading the CAN Status (CANSTS) register clears the CAN Interrupt (CANINT) register, if it is
pending.
CAN Status (CANSTS)
CAN0 base: 0x4004.0000
CAN1 base: 0x4004.1000
Offset 0x004
Type RW, reset 0x0000.0000
16171819202122232425262728293031
reserved
ROROROROROROROROROROROROROROROROType
0000000000000000Reset
0123456789101112131415
LECTXOKRXOKEPASSEWARNBOFFreserved
RWRWRWRWRWROROROROROROROROROROROType
0000000000000000Reset
DescriptionResetTypeNameBit/Field
Software should not rely on the value of a reserved bit. To provide
compatibility with future products, the value of a reserved bit should be
preserved across a read-modify-write operation.
0x0000.00ROreserved31:8
Bus-Off Status
DescriptionValue
The CAN controller is not in bus-off state.0
The CAN controller is in bus-off state.1
0ROBOFF7
Warning Status
DescriptionValue
Both error counters are below the error warning limit of
96.
0
At least one of the error counters has reached the error
warning limit of 96.
1
0ROEWARN6
June 18, 20141380
Texas Instruments-Production Data
Controller Area Network (CAN) Module
