Register 83: Quadrature Encoder Interface Software Reset (SRQEI), offset
0x544
The SRQEI register provides software the capability to reset the available QEI modules.
A peripheral is reset by software using a simple two-step process:
1. Software sets a bit (or bits) in the SRQEI register. While the SRQEI bit is 1, the peripheral is
held in reset.
2. Software completes the reset process by clearing the SRQEI bit.
There may be latency from the clearing of the SRQEI bit to when the peripheral is ready for use.
Software should check the corresponding PRQEI bit to verify that the QEI Module registers are
ready to be accessed.
Important: This register should be used to reset the QEI modules.
Quadrature Encoder Interface Software Reset (SRQEI)
Base 0x400F.E000
Offset 0x544
Type RW, reset 0x0000.0000
16171819202122232425262728293031
reserved
ROROROROROROROROROROROROROROROROType
0000000000000000Reset
0123456789101112131415
R0reserved
RWROROROROROROROROROROROROROROROType
0000000000000000Reset
DescriptionResetTypeNameBit/Field
Software should not rely on the value of a reserved bit. To provide
compatibility with future products, the value of a reserved bit should be
preserved across a read-modify-write operation.
0ROreserved31:1
QEI Module 0 Software Reset
DescriptionValue
QEI module 0 is not reset.0
QEI module 0 is reset.1
0RWR00
375June 18, 2014
Texas Instruments-Production Data
Tiva
™
TM4C1294NCPDT Microcontroller
