Register 23: EEPROM Support Control and Status (EESUPP), offset 0x01C
The EESUPP register indicates if internal operations are required because an internal copy buffer
must be erased or a programming failure has occurred and the operation must be completed. These
conditions are explained below as well as in more detail in the section called “Error During
Programming” on page 619.
■ If either PRETRY or ERETRY is set indicating that an operation must be completed, setting the
START bit causes the operation to be performed again
■ The PRETRY and ERETRY bits are cleared automatically after the failed operation has been
successfully completed.
These bits are not changed by reset, so any condition that occurred before a reset is still indicated
after a reset.
EEPROM Support Control and Status (EESUPP)
Base 0x400A.F000
Offset 0x01C
Type RW, reset -
16171819202122232425262728293031
reserved
ROROROROROROROROROROROROROROROROType
0000000000000000Reset
0123456789101112131415
reservedERETRYPRETRYreserved
ROROROROROROROROROROROROROROROROType
00--000000000000Reset
DescriptionResetTypeNameBit/Field
Software should not rely on the value of a reserved bit. To provide
compatibility with future products, the value of a reserved bit should be
preserved across a read-modify-write operation.
0x0000.000ROreserved31:4
Programming Must Be Retried
DescriptionValue
Programming has not failed.0
Programming from a copy in either direction failed to complete.1
-ROPRETRY3
Erase Must Be Retried
DescriptionValue
Erasing has not failed.0
Erasing failed to complete. If the failed erase is due to the erase
of a main buffer, the copy is performed after the erase completes
successfully.
1
-ROERETRY2
Software should not rely on the value of a reserved bit. To provide
compatibility with future products, the value of a reserved bit should be
preserved across a read-modify-write operation.
0ROreserved1:0
June 18, 2014658
Texas Instruments-Production Data
Internal Memory
