Table 5-11. System Control Register Map (continued)
See
page
DescriptionResetTypeNameOffset
423
Quadrature Encoder Interface Sleep Mode Clock Gating
Control
0x0000.0000RWSCGCQEI0x744
424EEPROM Sleep Mode Clock Gating Control0x0000.0000RWSCGCEEPROM0x758
425CRC Module Sleep Mode Clock Gating Control0x0000.0000RWSCGCCCM0x774
426Ethernet MAC Sleep Mode Clock Gating Control0x0000.0000RWSCGCEMAC0x79C
427Watchdog Timer Deep-Sleep Mode Clock Gating Control0x0000.0000RWDCGCWD0x800
428
16/32-Bit General-Purpose Timer Deep-Sleep Mode
Clock Gating Control
0x0000.0000RWDCGCTIMER0x804
430
General-Purpose Input/Output Deep-Sleep Mode Clock
Gating Control
0x0000.0000RWDCGCGPIO0x808
433
Micro Direct Memory Access Deep-Sleep Mode Clock
Gating Control
0x0000.0000RWDCGCDMA0x80C
434EPI Deep-Sleep Mode Clock Gating Control0x0000.0000RWDCGCEPI0x810
435Hibernation Deep-Sleep Mode Clock Gating Control0x0000.0001RWDCGCHIB0x814
436
Universal Asynchronous Receiver/Transmitter
Deep-Sleep Mode Clock Gating Control
0x0000.0000RWDCGCUART0x818
438
Synchronous Serial Interface Deep-Sleep Mode Clock
Gating Control
0x0000.0000RWDCGCSSI0x81C
439
Inter-Integrated Circuit Deep-Sleep Mode Clock Gating
Control
0x0000.0000RWDCGCI2C0x820
441
Universal Serial Bus Deep-Sleep Mode Clock Gating
Control
0x0000.0000RWDCGCUSB0x828
442Ethernet PHY Deep-Sleep Mode Clock Gating Control0x0000.0000RWDCGCEPHY0x830
443
Controller Area Network Deep-Sleep Mode Clock Gating
Control
0x0000.0000RWDCGCCAN0x834
444
Analog-to-Digital Converter Deep-Sleep Mode Clock
Gating Control
0x0000.0000RWDCGCADC0x838
445
Analog Comparator Deep-Sleep Mode Clock Gating
Control
0x0000.0000RWDCGCACMP0x83C
446
Pulse Width Modulator Deep-Sleep Mode Clock Gating
Control
0x0000.0000RWDCGCPWM0x840
447
Quadrature Encoder Interface Deep-Sleep Mode Clock
Gating Control
0x0000.0000RWDCGCQEI0x844
448EEPROM Deep-Sleep Mode Clock Gating Control0x0000.0000RWDCGCEEPROM0x858
449CRC Module Deep-Sleep Mode Clock Gating Control0x0000.0000RWDCGCCCM0x874
450Ethernet MAC Deep-Sleep Mode Clock Gating Control0x0000.0000RWDCGCEMAC0x89C
451Watchdog Timer Power Control0x0000.0003RWPCWD0x900
45316/32-Bit General-Purpose Timer Power Control0x0000.00FFRWPCTIMER0x904
June 18, 2014252
