Register 52: Analog-to-Digital Converter Peripheral Present (PPADC), offset
0x338
The PPADC register provides software information regarding the ADC modules.
Important: This register should be used to determine which ADC modules are implemented on
this microcontroller.
Analog-to-Digital Converter Peripheral Present (PPADC)
Base 0x400F.E000
Offset 0x338
Type RO, reset 0x0000.0003
16171819202122232425262728293031
reserved
ROROROROROROROROROROROROROROROROType
0000000000000000Reset
0123456789101112131415
P0P1reserved
ROROROROROROROROROROROROROROROROType
1100000000000000Reset
DescriptionResetTypeNameBit/Field
Software should not rely on the value of a reserved bit. To provide
compatibility with future products, the value of a reserved bit should be
preserved across a read-modify-write operation.
0ROreserved31:2
ADC Module 1 Present
DescriptionValue
ADC module 1 is not present.0
ADC module 1 is present.1
0x1ROP11
ADC Module 0 Present
DescriptionValue
ADC module 0 is not present.0
ADC module 0 is present.1
0x1ROP00
June 18, 2014338
Texas Instruments-Production Data
System Control
