Texas Instruments TM4C1294NCPDT User Manual

Register 56: ADC Digital Comparator Range 0 (ADCDCCMP0), offset 0xE40
Register 57: ADC Digital Comparator Range 1 (ADCDCCMP1), offset 0xE44
Register 58: ADC Digital Comparator Range 2 (ADCDCCMP2), offset 0xE48
Register 59: ADC Digital Comparator Range 3 (ADCDCCMP3), offset 0xE4C
Register 60: ADC Digital Comparator Range 4 (ADCDCCMP4), offset 0xE50
Register 61: ADC Digital Comparator Range 5 (ADCDCCMP5), offset 0xE54
Register 62: ADC Digital Comparator Range 6 (ADCDCCMP6), offset 0xE58
Register 63: ADC Digital Comparator Range 7 (ADCDCCMP7), offset 0xE5C
This register defines the comparison values that are used to determine if the ADC conversion data
falls in the appropriate operating region.
Note: The value in the COMP1 field must be greater than or equal to the value in the COMP0 field
or unexpected results can occur.
ADC Digital Comparator Range n (ADCDCCMPn)
ADC0 base: 0x4003.8000
ADC1 base: 0x4003.9000
Offset 0xE40
Type RW, reset 0x0000.0000
16171819202122232425262728293031
COMP1reserved
RWRWRWRWRWRWRWRWRWRWRWRWROROROROType
0000000000000000Reset
0123456789101112131415
COMP0reserved
RWRWRWRWRWRWRWRWRWRWRWRWROROROROType
0000000000000000Reset
DescriptionResetTypeNameBit/Field
Software should not rely on the value of a reserved bit. To provide
compatibility with future products, the value of a reserved bit should be
preserved across a read-modify-write operation.
0x0ROreserved31:28
Compare 1
The value in this field is compared against the ADC conversion data.
The result of the comparison is used to determine if the data lies within
the high-band region.
Note that the value of COMP1 must be greater than or equal to the value
of COMP0.
0x000RWCOMP127:16
Software should not rely on the value of a reserved bit. To provide
compatibility with future products, the value of a reserved bit should be
preserved across a read-modify-write operation.
0x0ROreserved15:12
Compare 0
The value in this field is compared against the ADC conversion data.
The result of the comparison is used to determine if the data lies within
the low-band region.
0x000RWCOMP011:0
June 18, 20141156
Texas Instruments-Production Data
Analog-to-Digital Converter (ADC)
