Note: Descriptions for all these registers can be found in the NDA version of the data sheet.
Table 21-2. List of Registers
DescriptionNameOffset
USB Device Functional AddressUSBFADDR0x000
USB PowerUSBPOWER0x001
USB Transmit Interrupt StatusUSBTXIS0x002
USB Receive Interrupt StatusUSBRXIS0x004
USB Transmit Interrupt EnableUSBTXIE0x006
USB Receive Interrupt EnableUSBRXIE0x008
USB General Interrupt StatusUSBIS0x00A
USB Interrupt EnableUSBIE0x00B
USB Frame ValueUSBFRAME0x00C
USB Endpoint IndexUSBEPIDX0x00E
USB Test ModeUSBTEST0x00F
USB FIFO Endpoint 0USBFIFO00x020
USB FIFO Endpoint 1USBFIFO10x024
USB FIFO Endpoint 2USBFIFO20x028
USB FIFO Endpoint 3USBFIFO30x02C
USB FIFO Endpoint 4USBFIFO40x030
USB FIFO Endpoint 5USBFIFO50x034
USB FIFO Endpoint 6USBFIFO60x038
USB FIFO Endpoint 7USBFIFO70x03C
USB Device ControlUSBDEVCTL0x060
USB Common ConfigurationUSBCCONF0x061
USB Transmit Dynamic FIFO SizingUSBTXFIFOSZ0x062
USB Receive Dynamic FIFO SizingUSBRXFIFOSZ0x063
USB Transmit FIFO Start AddressUSBTXFIFOADD0x064
USB Receive FIFO Start AddressUSBRXFIFOADD0x066
USB ULPI VBUS ControlULPIVBUSCTL0x070
USB ULPI Register DataULPIREGDATA0x074
USB ULPI Register AddressULPIREGADDR0x075
USB ULPI Register ControlULPIREGCTL0x076
USB Endpoint InformationUSBEPINFO0x078
USB RAM InformationUSBRAMINFO0x079
USB Connect TimingUSBCONTIM0x07A
USB OTG VBUS Pulse TimingUSBVPLEN0x07B
USB High-Speed Last Transaction to End of Frame TimingUSBHSEOF0x07C
USB Full-Speed Last Transaction to End of Frame TimingUSBFSEOF0x07D
USB Low-Speed Last Transaction to End of Frame TimingUSBLSEOF0x07E
USB Transmit Functional Address Endpoint 0USBTXFUNCADDR00x080
USB Transmit Hub Address Endpoint 0USBTXHUBADDR00x082
USB Transmit Hub Port Endpoint 0USBTXHUBPORT00x083
USB Transmit Functional Address Endpoint 1USBTXFUNCADDR10x088
1647June 18, 2014
Texas Instruments-Production Data
Tiva
™
TM4C1294NCPDT Microcontroller
