Register 19: EEPROM Current Offset (EEOFFSET), offset 0x008
The EEOFFSET register is used to select the EEPROM word to read or write within the block
selected by the EEBLOCK register. The value is a word offset into the block. Because accesses to
the EERDWRINC register change the offset, software can read the contents of this register to
determine the current offset.
EEPROM Current Offset (EEOFFSET)
Base 0x400A.F000
Offset 0x008
Type RW, reset 0x0000.0000
16171819202122232425262728293031
reserved
ROROROROROROROROROROROROROROROROType
0000000000000000Reset
0123456789101112131415
OFFSETreserved
RWRWRWRWROROROROROROROROROROROROType
0000000000000000Reset
DescriptionResetTypeNameBit/Field
Software should not rely on the value of a reserved bit. To provide
compatibility with future products, the value of a reserved bit should be
preserved across a read-modify-write operation.
0x0000.000ROreserved31:4
Current Address Offset
This value is the current address specified as an offset into the block
selected by the EEBLOCK register. Once configured, the read-write
registers, EERDRWR and EERDWRINC, operate against that address.
The offset is automatically incremented by the EERDWRINC register,
with wrap around within the block, which means the offset is incremented
from 15 back to 0.
0x0RWOFFSET3:0
653June 18, 2014
Texas Instruments-Production Data
