Register 48: PWM0 Generator B Control (PWM0GENB), offset 0x064
Register 49: PWM1 Generator B Control (PWM1GENB), offset 0x0A4
Register 50: PWM2 Generator B Control (PWM2GENB), offset 0x0E4
Register 51: PWM3 Generator B Control (PWM3GENB), offset 0x124
These registers control the generation of the pwmB signal based on the load and zero output pulses
from the counter, as well as the compare A and compare B pulses from the comparators
(PWM0GENB controls the PWM generator 0 block, and so on). When the counter is running in
Count-Down mode, only four of these events occur; when running in Count-Up/Down mode, all six
occur. These events provide great flexibility in the positioning and duty cycle of the resulting PWM
signal.
The PWM0GENB register controls generation of the pwm0B signal; PWM1GENB, the pwm1B
signal; PWM2GENB, the pwm2B signal; and PWM3GENB, the pwm3B signal.
If a zero or load event coincides with a compare A or compare B event, the zero or load action is
taken and the compare A or compare B action is ignored. If a compare A event coincides with a
compare B event, the compare B action is taken and the compare A action is ignored.
If the Generator B update mode is immediate (based on the GENBUPD field encoding in the PWMnCTL
register), the ACTCMPBD, ACTCMPBU, ACTCMPAD, ACTCMPAU, ACTLOAD, and ACTZERO values are
used immediately. If the update mode is locally synchronized, these values are used the next time
the counter reaches zero. If the update mode is globally synchronized, these values are used the
next time the counter reaches zero after a synchronous update has been requested through the
PWM Master Control (PWMCTL) register (see page 1683). If this register is rewritten before the
actual update occurs, the previous value is never used and is lost.
PWMn Generator B Control (PWMnGENB), offset 0x064
PWM0 base: 0x4002.8000
Offset 0x064
Type RW, reset 0x0000.0000
16171819202122232425262728293031
reserved
ROROROROROROROROROROROROROROROROType
0000000000000000Reset
0123456789101112131415
ACTZEROACTLOADACTCMPAUACTCMPADACTCMPBUACTCMPBDreserved
RWRWRWRWRWRWRWRWRWRWRWRWROROROROType
0000000000000000Reset
DescriptionResetTypeNameBit/Field
Software should not rely on the value of a reserved bit. To provide
compatibility with future products, the value of a reserved bit should be
preserved across a read-modify-write operation.
0x0000.0ROreserved31:12
1727June 18, 2014
Texas Instruments-Production Data
Tiva
™
TM4C1294NCPDT Microcontroller
