Register 74: Universal Asynchronous Receiver/Transmitter Software Reset
(SRUART), offset 0x518
The SRUART register provides software the capability to reset the available UART modules.
A peripheral is reset by software using a simple two-step process:
1. Software sets a bit (or bits) in the SRUART register. While the SRUART bit is 1, the peripheral
is held in reset.
2. Software completes the reset process by clearing the SRUART bit.
There may be latency from the clearing of the SRUART bit to when the peripheral is ready for use.
Software should check the corresponding PRUART bit to verify that the UART Module registers are
ready to be accessed.
Important: This register should be used to reset the UART modules.
Universal Asynchronous Receiver/Transmitter Software Reset (SRUART)
Base 0x400F.E000
Offset 0x518
Type RW, reset 0x0000.0000
16171819202122232425262728293031
reserved
ROROROROROROROROROROROROROROROROType
0000000000000000Reset
0123456789101112131415
R0R1R2R3R4R5R6R7reserved
RWRWRWRWRWRWRWRWROROROROROROROROType
0000000000000000Reset
DescriptionResetTypeNameBit/Field
Software should not rely on the value of a reserved bit. To provide
compatibility with future products, the value of a reserved bit should be
preserved across a read-modify-write operation.
0ROreserved31:8
UART Module 7 Software Reset
DescriptionValue
UART module 7 is not reset.0
UART module 7 is reset.1
0RWR77
UART Module 6 Software Reset
DescriptionValue
UART module 6 is not reset.0
UART module 6 is reset.1
0RWR66
363June 18, 2014
Texas Instruments-Production Data
Tiva
™
TM4C1294NCPDT Microcontroller
