Register 117: Controller Area Network Sleep Mode Clock Gating Control
(SCGCCAN), offset 0x734
The SCGCCAN register provides software the capability to enable and disable the CAN modules
in sleep mode. When enabled, a module is provided a clock. When disabled, the clock is disabled
to save power.
Important: This register should be used to control the clocking for the CAN modules.
Controller Area Network Sleep Mode Clock Gating Control (SCGCCAN)
Base 0x400F.E000
Offset 0x734
Type RW, reset 0x0000.0000
16171819202122232425262728293031
reserved
ROROROROROROROROROROROROROROROROType
0000000000000000Reset
0123456789101112131415
S0S1reserved
RWRWROROROROROROROROROROROROROROType
0000000000000000Reset
DescriptionResetTypeNameBit/Field
Software should not rely on the value of a reserved bit. To provide
compatibility with future products, the value of a reserved bit should be
preserved across a read-modify-write operation.
0ROreserved31:2
CAN Module 1 Sleep Mode Clock Gating Control
DescriptionValue
CAN module 1 is disabled in sleep mode.0
Enable and provide a clock to CAN module 1 in sleep mode.1
0RWS11
CAN Module 0 Sleep Mode Clock Gating Control
DescriptionValue
CAN module 0 is disabled.0
Enable and provide a clock to CAN module 0 in sleep mode.1
0RWS00
419June 18, 2014
Texas Instruments-Production Data
Tiva
™
TM4C1294NCPDT Microcontroller
