Register 26: ADC Sample Sequence 0 Digital Comparator Select (ADCSSDC0),
offset 0x054
This register determines which digital comparator receives the sample from the given conversion
on Sample Sequence 0, if the corresponding SnDCOP bit in the ADCSSOP0 register is set.
ADC Sample Sequence 0 Digital Comparator Select (ADCSSDC0)
ADC0 base: 0x4003.8000
ADC1 base: 0x4003.9000
Offset 0x054
Type RW, reset 0x0000.0000
16171819202122232425262728293031
S4DCSELS5DCSELS6DCSELS7DCSEL
RWRWRWRWRWRWRWRWRWRWRWRWRWRWRWRWType
0000000000000000Reset
0123456789101112131415
S0DCSELS1DCSELS2DCSELS3DCSEL
RWRWRWRWRWRWRWRWRWRWRWRWRWRWRWRWType
0000000000000000Reset
DescriptionResetTypeNameBit/Field
Sample 7 Digital Comparator Select
When the S7DCOP bit in the ADCSSOP0 register is set, this field
indicates which digital comparator unit (and its associated set of control
registers) receives the eighth sample from Sample Sequencer 0.
Note: Values not listed are reserved.
DescriptionValue
Digital Comparator Unit 0 (ADCDCCMP0 and ADCDCCTL0)0x0
Digital Comparator Unit 1 (ADCDCCMP1 and ADCDCCTL1)0x1
Digital Comparator Unit 2 (ADCDCCMP2 and ADCDCCTL2)0x2
Digital Comparator Unit 3 (ADCDCCMP3 and ADCDCCTL3)0x3
Digital Comparator Unit 4 (ADCDCCMP4 and ADCDCCTL4)0x4
Digital Comparator Unit 5 (ADCDCCMP5 and ADCDCCTL5)0x5
Digital Comparator Unit 6 (ADCDCCMP6 and ADCDCCTL6)0x6
Digital Comparator Unit 7 (ADCDCCMP7 and ADCDCCTL7)0x7
0x0RWS7DCSEL31:28
Sample 6 Digital Comparator Select
This field has the same encodings as S7DCSEL but is used during the
seventh sample.
0x0RWS6DCSEL27:24
Sample 5 Digital Comparator Select
This field has the same encodings as S7DCSEL but is used during the
sixth sample.
0x0RWS5DCSEL23:20
Sample 4 Digital Comparator Select
This field has the same encodings as S7DCSEL but is used during the
fifth sample.
0x0RWS4DCSEL19:16
Sample 3 Digital Comparator Select
This field has the same encodings as S7DCSEL but is used during the
fourth sample.
0x0RWS3DCSEL15:12
1123June 18, 2014
Texas Instruments-Production Data
Tiva
™
TM4C1294NCPDT Microcontroller
