Register 17: EEPROM Size Information (EESIZE), offset 0x000
The EESIZE register indicates the number of 16-word blocks and 32-bit words in the EEPROM.
EEPROM Size Information (EESIZE)
Base 0x400A.F000
Offset 0x000
Type RO, reset 0x0060.0600
16171819202122232425262728293031
BLKCNTreserved
ROROROROROROROROROROROROROROROROType
0000011000000000Reset
0123456789101112131415
WORDCNT
ROROROROROROROROROROROROROROROROType
0000000001100000Reset
DescriptionResetTypeNameBit/Field
Software should not rely on the value of a reserved bit. To provide
compatibility with future products, the value of a reserved bit should be
preserved across a read-modify-write operation.
0ROreserved31:27
Number of 16-Word Blocks
This value encoded in this field describes the number of 16-word blocks
in the EEPROM.
0x60ROBLKCNT26:16
Number of 32-Bit Words
This value encoded in this field describes the number of 32-bit words
in the EEPROM.
0x600ROWORDCNT15:0
