Texas Instruments TM4C1294NCPDT User Manual

22.5 Register Map
Table 22-5 on page 1659 lists the comparator registers. The offset listed is a hexadecimal increment
to the register's address, relative to the Analog Comparator base address of 0x4003.C000. Note
that the analog comparator clock must be enabled before the registers can be programmed (see
page 397). There must be a delay of 3 system clocks after the analog comparator module clock is
enabled before any analog comparator module registers are accessed.
Table 22-5. Analog Comparators Register Map
See
page
DescriptionResetTypeNameOffset
1660Analog Comparator Masked Interrupt Status0x0000.0000RW1CACMIS0x000
1661Analog Comparator Raw Interrupt Status0x0000.0000ROACRIS0x004
1662Analog Comparator Interrupt Enable0x0000.0000RWACINTEN0x008
1663Analog Comparator Reference Voltage Control0x0000.0000RWACREFCTL0x010
1664Analog Comparator Status 00x0000.0000ROACSTAT00x020
1665Analog Comparator Control 00x0000.0000RWACCTL00x024
1664Analog Comparator Status 10x0000.0000ROACSTAT10x040
1665Analog Comparator Control 10x0000.0000RWACCTL10x044
1664Analog Comparator Status 20x0000.0000ROACSTAT20x060
1665Analog Comparator Control 20x0000.0000RWACCTL20x064
1667Analog Comparator Peripheral Properties0x0007.0007ROACMPPP0xFC0
22.6 Register Descriptions
The remainder of this section lists and describes the Analog Comparator registers, in numerical
order by address offset.
1659June 18, 2014
Texas Instruments-Production Data
Tiva
™
TM4C1294NCPDT Microcontroller
