Register 75: Synchronous Serial Interface Software Reset (SRSSI), offset
0x51C
The SRSSI register provides software the capability to reset the available SSI modules.
A peripheral is reset by software using a simple two-step process:
1. Software sets a bit (or bits) in the SRSSI register. While the SRSSI bit is 1, the peripheral is
held in reset.
2. Software completes the reset process by clearing the SRSSI bit.
There may be latency from the clearing of the SRSSI bit to when the peripheral is ready for use.
Software should check the corresponding PRSSI bit to verify that the SSI Module registers are ready
to be accessed.
Important: This register should be used to reset the SSI modules.
Synchronous Serial Interface Software Reset (SRSSI)
Base 0x400F.E000
Offset 0x51C
Type RW, reset 0x0000.0000
16171819202122232425262728293031
reserved
ROROROROROROROROROROROROROROROROType
0000000000000000Reset
0123456789101112131415
R0R1R2R3reserved
RWRWRWRWROROROROROROROROROROROROType
0000000000000000Reset
DescriptionResetTypeNameBit/Field
Software should not rely on the value of a reserved bit. To provide
compatibility with future products, the value of a reserved bit should be
preserved across a read-modify-write operation.
0ROreserved31:4
SSI Module 3 Software Reset
DescriptionValue
SSI module 3 is not reset.0
SSI module 3 is reset.1
0RWR33
SSI Module 2 Software Reset
DescriptionValue
SSI module 2 is not reset.0
SSI module 2 is reset.1
0RWR22
365June 18, 2014
Texas Instruments-Production Data
Tiva
™
TM4C1294NCPDT Microcontroller
