Register 137: Analog-to-Digital Converter Deep-Sleep Mode Clock Gating
Control (DCGCADC), offset 0x838
The DCGCADC register provides software the capability to enable and disable the ADC modules
in deep-sleep mode. When enabled, a module is provided a clock. When disabled, the clock is
disabled to save power.
Important: This register should be used to control the clocking for the ADC modules.
Analog-to-Digital Converter Deep-Sleep Mode Clock Gating Control (DCGCADC)
Base 0x400F.E000
Offset 0x838
Type RW, reset 0x0000.0000
16171819202122232425262728293031
reserved
ROROROROROROROROROROROROROROROROType
0000000000000000Reset
0123456789101112131415
D0D1reserved
RWRWROROROROROROROROROROROROROROType
0000000000000000Reset
DescriptionResetTypeNameBit/Field
Software should not rely on the value of a reserved bit. To provide
compatibility with future products, the value of a reserved bit should be
preserved across a read-modify-write operation.
0ROreserved31:2
ADC Module 1 Deep-Sleep Mode Clock Gating Control
DescriptionValue
ADC module 1 is disabled in deep-sleep mode.0
Enable and provide a clock to ADC module 1 in deep-sleep
mode.
1
0RWD11
ADC Module 0 Deep-Sleep Mode Clock Gating Control
DescriptionValue
ADC module 0 is disabled in deep-sleep mode.0
Enable and provide a clock to ADC module 0 in deep-sleep
mode.
1
0RWD00
June 18, 2014444
