Texas Instruments TM4C1294NCPDT User Manual

Register 88: 16/32-Bit General-Purpose Timer Run Mode Clock Gating Control
(RCGCTIMER), offset 0x604
The RCGCGPT32 register provides software the capability to enable and disable 16/32-bit timer
modules in Run mode. When enabled, a module is provided a clock and accesses to module registers
are allowed. When disabled, the clock is disabled to save power and accesses to module registers
generate a bus fault.
Important: This register should be used to control the clocking for the timer modules.
16/32-Bit General-Purpose Timer Run Mode Clock Gating Control (RCGCTIMER)
Base 0x400F.E000
Offset 0x604
Type RW, reset 0x0000.0000
16171819202122232425262728293031
reserved
ROROROROROROROROROROROROROROROROType
0000000000000000Reset
0123456789101112131415
R0R1R2R3R4R5R6R7reserved
RWRWRWRWRWRWRWRWROROROROROROROROType
0000000000000000Reset
DescriptionResetTypeNameBit/Field
Software should not rely on the value of a reserved bit. To provide
compatibility with future products, the value of a reserved bit should be
preserved across a read-modify-write operation.
0ROreserved31:8
16/32-Bit General-Purpose Timer 7 Run Mode Clock Gating Control
DescriptionValue
16/32-bit general-purpose timer module 7 is disabled.0
Enable and provide a clock to 16/32-bit general-purpose timer
module 7 in Run mode.
1
0RWR77
16/32-Bit General-Purpose Timer 6 Run Mode Clock Gating Control
DescriptionValue
16/32-bit general-purpose timer module 6 is disabled.0
Enable and provide a clock to 16/32-bit general-purpose timer
module 6 in Run mode.
1
0RWR66
16/32-Bit General-Purpose Timer 5 Run Mode Clock Gating Control
DescriptionValue
16/32-bit general-purpose timer module 5 is disabled.0
Enable and provide a clock to 16/32-bit general-purpose timer
module 5 in Run mode.
1
0RWR55
June 18, 2014380
