Register 44: EPI Host-Bus 8 Timing Extension (EPIHB8TIME4), offset 0x31C
Important: The MODE field in the EPICFG register determines which configuration is enabled.
For EPIHB8TIME4 to be valid, the MODE field must be 0x2.
EPI Host-Bus 8 Timing Extension (EPIHB8TIME4)
Base 0x400D.0000
Offset 0x31C
Type RW, reset 0x0002.2000
16171819202122232425262728293031
reservedIRDYDLYreserved
RORORORORORORORORWRWROROROROROROType
0000000000000000Reset
0123456789101112131415
RDWSMreservedWRWSMreservedCAPWIDTHreserved
RWRORORORWRORORORORORORORWRWROROType
0000000000000101Reset
DescriptionResetTypeNameBit/Field
Software should not rely on the value of a reserved bit. To provide
compatibility with future products, the value of a reserved bit should be
preserved across a read-modify-write operation.
0x00ROreserved31:26
CS3n Input Ready Delay
DescriptionValue
reserved0
Stall begins one EPI clocks past iRDY low being sampled on
the rising edge of EPIO clock.
1
Stall begins two EPI clocks past iRDY low being sampled on
the rising edge of EPIO clock.
2
Stall begins three EPI clocks past iRDY low being sampled on
the rising edge of EPIO clock.
3
0x0RWIRDYDLY25:24
Software should not rely on the value of a reserved bit. To provide
compatibility with future products, the value of a reserved bit should be
preserved across a read-modify-write operation.
Bits [18:16] have the same RTL implementation as the HB16TIMEn
register, even though this is not used in HB8 mode. Thus, the reset
value of 0x2 is carried over from the PSRAMSZ bits of HB16TIMEn.
0x002ROreserved23:14
CS3n Inter-transfer Capture Width
Controls the delay between Host-Bus transfers.
DescriptionValue
Reserved0x0
1 EPI clock.0x1
2 EPI clock.0x2
Reserved0x3
0x2RWCAPWIDTH13:12
941June 18, 2014
Texas Instruments-Production Data
Tiva
™
TM4C1294NCPDT Microcontroller
