Register 6: GPIO Interrupt Mask (GPIOIM), offset 0x410
The GPIOIM register is the interrupt mask register. Setting a bit in the GPIOIM register allows
interrupts that are generated by the corresponding pin to be sent to the interrupt controller on the
combined interrupt signal. Clearing a bit prevents an interrupt on the corresponding pin from being
sent to the interrupt controller. All bits are cleared by a reset.
GPIO Interrupt Mask (GPIOIM)
GPIO Port A (AHB) base: 0x4005.8000
GPIO Port B (AHB) base: 0x4005.9000
GPIO Port C (AHB) base: 0x4005.A000
GPIO Port D (AHB) base: 0x4005.B000
GPIO Port E (AHB) base: 0x4005.C000
GPIO Port F (AHB) base: 0x4005.D000
GPIO Port G (AHB) base: 0x4005.E000
GPIO Port H (AHB) base: 0x4005.F000
GPIO Port J (AHB) base: 0x4006.0000
GPIO Port K (AHB) base: 0x4006.1000
GPIO Port L (AHB) base: 0x4006.2000
GPIO Port M (AHB) base: 0x4006.3000
GPIO Port N (AHB) base: 0x4006.4000
GPIO Port P (AHB) base: 0x4006.5000
GPIO Port Q (AHB) base: 0x4006.6000
Offset 0x410
Type RW, reset 0x0000.0000
16171819202122232425262728293031
reserved
ROROROROROROROROROROROROROROROROType
0000000000000000Reset
0123456789101112131415
IMEDMAIMEreserved
RWRWRWRWRWRWRWRWRWROROROROROROROType
0000000000000000Reset
DescriptionResetTypeNameBit/Field
Software should not rely on the value of a reserved bit. To provide
compatibility with future products, the value of a reserved bit should be
preserved across a read-modify-write operation.
0ROreserved31:9
GPIO uDMA Done Interrupt Mask Enable
DescriptionValue
The µDMA done interrupt is masked and does not cause an
interrupt.
0
The µDMA done interrupt is not masked and can generate an
interrupt to the interrupt controller.
1
0RWDMAIME8
GPIO Interrupt Mask Enable
DescriptionValue
The interrupt from the corresponding pin is masked.0
The interrupt from the corresponding pin is sent to the interrupt
controller.
1
0x00RWIME7:0
June 18, 2014764
Texas Instruments-Production Data
General-Purpose Input/Outputs (GPIOs)
