Register 18: I
2
C Slave Raw Interrupt Status (I2CSRIS), offset 0x810
This register specifies whether an interrupt is pending.
I2C Slave Raw Interrupt Status (I2CSRIS)
I2C 0 base: 0x4002.0000
I2C 1 base: 0x4002.1000
I2C 2 base: 0x4002.2000
I2C 3 base: 0x4002.3000
I2C 4 base: 0x400C.0000
I2C 5 base: 0x400C.1000
I2C 6 base: 0x400C.2000
I2C 7 base: 0x400C.3000
I2C 8 base: 0x400B.8000
I2C 9 base: 0x400B.9000
Offset 0x810
Type RO, reset 0x0000.0000
16171819202122232425262728293031
reserved
ROROROROROROROROROROROROROROROROType
0000000000000000Reset
0123456789101112131415
DATARIS
STARTRIS
STOPRIS
DMARXRISDMATXRIS
TXRISRXRISTXFERISRXFFRISreserved
ROROROROROROROROROROROROROROROROType
0000000000000000Reset
DescriptionResetTypeNameBit/Field
Software should not rely on the value of a reserved bit. To provide
compatibility with future products, the value of a reserved bit should be
preserved across a read-modify-write operation.
0ROreserved31:9
Receive FIFO Full Raw Interrupt Status
DescriptionValue
No interrupt0
The Receive FIFO Full interrupt is pending.1
This bit is cleared by writing a 1 to the RXFFIC bit in the I2CSICR
register.
0RORXFFRIS8
Transmit FIFO Empty Raw Interrupt Status
DescriptionValue
No interrupt0
The Transmit FIFO Empty interrupt is pending.1
This bit is cleared by writing a 1 to the TXFEIC bit in the I2CSICR
register.
Note that if the TXFERIS interrupt is cleared (by setting the TXFEIC bit)
when the TX FIFO is empty, the TXFERIS interrupt does not reassert
even though the TX FIFO remains empty in this situation.
0ROTXFERIS7
June 18, 20141338
Texas Instruments-Production Data
Inter-Integrated Circuit (I
2
C) Interface
