Register 14: Hibernation Calendar 0 (HIBCAL0), offset 0x310
The Hibernation Calendar 0 (HIBCAL0) register is used when the CALEN bit is set in the
HIBCALCTL register.
Hibernation Calendar 0 (HIBCAL0)
Base 0x400F.C000
Offset 0x310
Type RO, reset 0x0000.0000
16171819202122232425262728293031
HRreservedAMPMreservedVALID
ROROROROROROROROROROROROROROROROType
0000000000000000Reset
0123456789101112131415
SECreservedMINreserved
ROROROROROROROROROROROROROROROROType
0000000000000000Reset
DescriptionResetTypeNameBit/Field
Valid Calendar Load
The calendar may take several cycles to update as the values roll over.
This bit indicates whether the HIBCAL0 register contents are valid.
DescriptionValue
Register currently updating or initializing0
HIBCAL0 register valid and ready.1
0ROVALID31
Software should not rely on the value of a reserved bit. To provide
compatibility with future products, the value of a reserved bit should be
preserved across a read-modify-write operation.
0ROreserved30:23
AM/PM Designation
This bit is used when CAL24=0 in the HIBCALCTL register.
DescriptionValue
AM0
PM1
0ROAMPM22
Software should not rely on the value of a reserved bit. To provide
compatibility with future products, the value of a reserved bit should be
preserved across a read-modify-write operation.
0ROreserved21
Hours
This field holds the hour information in hexadecimal.
For military time, bits 20:16 range from 0x0 to 0x17 (0 to 23 hours).
For standard time (AM/PM mode) bits 20:16 range from 0x0 to 0x11,
with 0x0 representing 12AM or 12 PM.
0ROHR20:16
Software should not rely on the value of a reserved bit. To provide
compatibility with future products, the value of a reserved bit should be
preserved across a read-modify-write operation.
0ROreserved15:14
June 18, 2014576
