Register 16: Hibernation Calendar Load 0 (HIBCALLD0), offset 0x320
The Hibernation Calendar Load (HIBCALLD0) register is used when the CALEN bit is set in the
HIBCALCTL register.
Note: This register is write-only; any reads to this register read back as zeros. Errant writes to the
HIBCALLD0/1 registers are protected by the Hibernate HIBLOCK register.
Hibernation Calendar Load 0 (HIBCALLD0)
Base 0x400F.C000
Offset 0x320
Type WO, reset 0x0000.0000
16171819202122232425262728293031
HRreservedAMPMreserved
WOWOWOWOWOROWOROROROROROROROROROType
0000000000000000Reset
0123456789101112131415
SECreservedMINreserved
WOWOWOWOWOWOROROWOWOWOWOWOWOROROType
0000000000000000Reset
DescriptionResetTypeNameBit/Field
Software should not rely on the value of a reserved bit. To provide
compatibility with future products, the value of a reserved bit should be
preserved across a read-modify-write operation.
0ROreserved31:23
AM/PM Designation
This bit is used when CAL24=0 in the HIBCALCTL register.
DescriptionValue
AM0
PM1
0WOAMPM22
Software should not rely on the value of a reserved bit. To provide
compatibility with future products, the value of a reserved bit should be
preserved across a read-modify-write operation.
0ROreserved21
Hours
This field holds the hour information in hexadecimal.
Bits 20:16 correspond to hex values from 0x0 to 0x17 (0 to 23 hours).
0WOHR20:16
Software should not rely on the value of a reserved bit. To provide
compatibility with future products, the value of a reserved bit should be
preserved across a read-modify-write operation.
0ROreserved15:14
Minutes
This field holds the minute information in hexadecimal.
Bits 13:8 correspond to hex values from 0x0 to 0x3B (0 to 59 minutes).
0WOMIN13:8
Software should not rely on the value of a reserved bit. To provide
compatibility with future products, the value of a reserved bit should be
preserved across a read-modify-write operation.
0ROreserved7:6
June 18, 2014580
Texas Instruments-Production Data
Hibernation Module
