Register 21: PLL Status (PLLSTAT), offset 0x168
This register shows the direct status of the PLL lock.
PLL Status (PLLSTAT)
Base 0x400F.E000
Offset 0x168
Type RO, reset 0x0000.0000
16171819202122232425262728293031
reserved
ROROROROROROROROROROROROROROROROType
0000000000000000Reset
0123456789101112131415
LOCKreserved
ROROROROROROROROROROROROROROROROType
0000000000000000Reset
DescriptionResetTypeNameBit/Field
Software should not rely on the value of a reserved bit. To provide
compatibility with future products, the value of a reserved bit should be
preserved across a read-modify-write operation.
0x0000.000ROreserved31:1
PLL Lock
DescriptionValue
The PLL is unpowered or is not yet locked.0
The PLL powered and locked.1
0x0ROLOCK0
June 18, 2014294
Texas Instruments-Production Data
System Control
