Note that the Watchdog Timer module clock must be enabled before the registers can be programmed
(see page 379).
Table 14-1. Watchdog Timers Register Map
See
page
DescriptionResetTypeNameOffset
1032Watchdog Load0xFFFF.FFFFRWWDTLOAD0x000
1033Watchdog Value0xFFFF.FFFFROWDTVALUE0x004
1034Watchdog Control
0x0000.0000
(WDT0)
0x8000.0000
(WDT1)
RWWDTCTL0x008
1036Watchdog Interrupt Clear-WOWDTICR0x00C
1037Watchdog Raw Interrupt Status0x0000.0000ROWDTRIS0x010
1038Watchdog Masked Interrupt Status0x0000.0000ROWDTMIS0x014
1039Watchdog Test0x0000.0000RWWDTTEST0x418
1040Watchdog Lock0x0000.0000RWWDTLOCK0xC00
1041Watchdog Peripheral Identification 40x0000.0000ROWDTPeriphID40xFD0
1042Watchdog Peripheral Identification 50x0000.0000ROWDTPeriphID50xFD4
1043Watchdog Peripheral Identification 60x0000.0000ROWDTPeriphID60xFD8
1044Watchdog Peripheral Identification 70x0000.0000ROWDTPeriphID70xFDC
1045Watchdog Peripheral Identification 00x0000.0005ROWDTPeriphID00xFE0
1046Watchdog Peripheral Identification 10x0000.0018ROWDTPeriphID10xFE4
1047Watchdog Peripheral Identification 20x0000.0018ROWDTPeriphID20xFE8
1048Watchdog Peripheral Identification 30x0000.0001ROWDTPeriphID30xFEC
1049Watchdog PrimeCell Identification 00x0000.000DROWDTPCellID00xFF0
1050Watchdog PrimeCell Identification 10x0000.00F0ROWDTPCellID10xFF4
1051Watchdog PrimeCell Identification 20x0000.0006ROWDTPCellID20xFF8
1052Watchdog PrimeCell Identification 30x0000.00B1ROWDTPCellID30xFFC
14.5 Register Descriptions
The remainder of this section lists and describes the WDT registers, in numerical order by address
offset.
1031June 18, 2014
Texas Instruments-Production Data
Tiva
™
TM4C1294NCPDT Microcontroller
