Register 76: Inter-Integrated Circuit Software Reset (SRI2C), offset 0x520
The SRI2C register provides software the capability to reset the available I
2
C modules.
A peripheral is reset by software using a simple two-step process:
1. Software sets a bit (or bits) in the SRI2C register. While the SRI2C bit is 1, the peripheral is
held in reset.
2. Software completes the reset process by clearing the SRI2C bit.
There may be latency from the clearing of the SRI2C bit to when the peripheral is ready for use.
Software should check the corresponding PRI2C bit to verify that the I
2
C Module registers are ready
to be accessed.
Important: This register should be used to reset the I
2
C modules.
Inter-Integrated Circuit Software Reset (SRI2C)
Base 0x400F.E000
Offset 0x520
Type RW, reset 0x0000.0000
16171819202122232425262728293031
reserved
ROROROROROROROROROROROROROROROROType
0000000000000000Reset
0123456789101112131415
R0R1R2R3R4R5R6R7R8R9reserved
RWRWRWRWRWRWRWRWRWRWROROROROROROType
0000000000000000Reset
DescriptionResetTypeNameBit/Field
Software should not rely on the value of a reserved bit. To provide
compatibility with future products, the value of a reserved bit should be
preserved across a read-modify-write operation.
0ROreserved31:10
I
2
C Module 9 Software Reset
DescriptionValue
I
2
C module 9 is not reset.0
I
2
C module 9 is reset.1
0RWR99
I
2
C Module 8 Software Reset
DescriptionValue
I
2
C module 8 is not reset.0
I
2
C module 8 is reset.1
0RWR88
I
2
C Module 7 Software Reset
DescriptionValue
I
2
C module 7 is not reset.0
I
2
C module 7 is reset.1
0RWR77
367June 18, 2014
Texas Instruments-Production Data
Tiva
™
TM4C1294NCPDT Microcontroller
