Register 10: PWM Fault Condition Value (PWMFAULTVAL), offset 0x024
This register specifies the output value driven on the MnPWMn signals during a fault condition if
enabled by the corresponding bit in the PWMFAULT register. Note that if the corresponding bit in
the PWMINVERT register is set, the output value is driven to the logical NOT of the bit value in this
register.
PWM Fault Condition Value (PWMFAULTVAL)
PWM0 base: 0x4002.8000
Offset 0x024
Type RW, reset 0x0000.0000
16171819202122232425262728293031
reserved
ROROROROROROROROROROROROROROROROType
0000000000000000Reset
0123456789101112131415
PWM0PWM1PWM2PWM3PWM4PWM5PWM6PWM7reserved
RWRWRWRWRWRWRWRWROROROROROROROROType
0000000000000000Reset
DescriptionResetTypeNameBit/Field
Software should not rely on the value of a reserved bit. To provide
compatibility with future products, the value of a reserved bit should be
preserved across a read-modify-write operation.
0x0000.00ROreserved31:8
MnPWM7 Fault Value
DescriptionValue
The MnPWM7 output signal is driven Low during fault conditions
if the FAULT7 bit in the PWMFAULT register is set.
0
The MnPWM7 output signal is driven High during fault conditions
if the FAULT7 bit in the PWMFAULT register is set.
1
0RWPWM77
MnPWM6 Fault Value
DescriptionValue
The MnPWM6 output signal is driven Low during fault conditions
if the FAULT6 bit in the PWMFAULT register is set.
0
The MnPWM6 output signal is driven High during fault conditions
if the FAULT6 bit in the PWMFAULT register is set.
1
0RWPWM66
MnPWM5 Fault Value
DescriptionValue
The MnPWM5 output signal is driven Low during fault conditions
if the FAULT5 bit in the PWMFAULT register is set.
0
The MnPWM5 output signal is driven High during fault conditions
if the FAULT5 bit in the PWMFAULT register is set.
1
0RWPWM55
June 18, 20141702
Texas Instruments-Production Data
Pulse Width Modulator (PWM)
