Register 5: Analog Comparator Status 0 (ACSTAT0), offset 0x020
Register 6: Analog Comparator Status 1 (ACSTAT1), offset 0x040
Register 7: Analog Comparator Status 2 (ACSTAT2), offset 0x060
These registers specify the current output value of the comparator.
Analog Comparator Status n (ACSTATn)
Base 0x4003.C000
Offset 0x020
Type RO, reset 0x0000.0000
16171819202122232425262728293031
reserved
ROROROROROROROROROROROROROROROROType
0000000000000000Reset
0123456789101112131415
reservedOVALreserved
ROROROROROROROROROROROROROROROROType
0000000000000000Reset
DescriptionResetTypeNameBit/Field
Software should not rely on the value of a reserved bit. To provide
compatibility with future products, the value of a reserved bit should be
preserved across a read-modify-write operation.
0x0000.000ROreserved31:2
Comparator Output Value
DescriptionValue
VIN- > VIN+0
VIN- < VIN+1
VIN - is the voltage on the Cn- pin. VIN+ is the voltage on the Cn+ pin,
the C0+ pin, or the internal voltage reference (V
IREF
) as defined by the
ASRCP bit in the ACCTL register.
0ROOVAL1
Software should not rely on the value of a reserved bit. To provide
compatibility with future products, the value of a reserved bit should be
preserved across a read-modify-write operation.
0ROreserved0
June 18, 20141664
Texas Instruments-Production Data
Analog Comparators
