Table 26-6. Possible Pin Assignments for Alternate Functions (continued)
GPIO FunctionAlternate Function# of Possible Assignments
EPI0S17 PL1
PL2EPI0S18
PL3EPI0S19
PQ0EPI0S20
PQ1EPI0S21
PQ2EPI0S22
PQ3EPI0S23
PK7EPI0S24
PK6EPI0S25
PL4EPI0S26
PB2EPI0S27
PB3EPI0S28
PK5EPI0S31
PK4EPI0S32
PL5EPI0S33
PN4EPI0S34
PN5EPI0S35
PC7EPI0S4
PC6EPI0S5
PC5EPI0S6
PC4EPI0S7
PA6EPI0S8
PA7EPI0S9
PB2I2C0SCL
PB3I2C0SDA
PG0I2C1SCL
PG1I2C1SDA
PK4I2C3SCL
PK5I2C3SDA
PK6I2C4SCL
PK7I2C4SDA
PA6I2C6SCL
PA7I2C6SDA
PA0I2C9SCL
PA1I2C9SDA
PL3IDX0
PF4M0FAULT0
PK6M0FAULT1
PK7M0FAULT2
PL0M0FAULT3
PF0M0PWM0
June 18, 20141812
Texas Instruments-Production Data
Signal Tables
