Texas Instruments TM4C1294NCPDT - Page 1681

Table 23-2. PWM Register Map (continued)
See
page
DescriptionResetTypeNameOffset
1718PWM2 Interrupt Status and Clear0x0000.0000RW1CPWM2ISC0x0CC
1720PWM2 Load0x0000.0000RWPWM2LOAD0x0D0
1721PWM2 Counter0x0000.0000ROPWM2COUNT0x0D4
1722PWM2 Compare A0x0000.0000RWPWM2CMPA0x0D8
1723PWM2 Compare B0x0000.0000RWPWM2CMPB0x0DC
1724PWM2 Generator A Control0x0000.0000RWPWM2GENA0x0E0
1727PWM2 Generator B Control0x0000.0000RWPWM2GENB0x0E4
1730PWM2 Dead-Band Control0x0000.0000RWPWM2DBCTL0x0E8
1731PWM2 Dead-Band Rising-Edge Delay0x0000.0000RWPWM2DBRISE0x0EC
1732PWM2 Dead-Band Falling-Edge-Delay0x0000.0000RWPWM2DBFALL0x0F0
1733PWM2 Fault Source 00x0000.0000RWPWM2FLTSRC00x0F4
1735PWM2 Fault Source 10x0000.0000RWPWM2FLTSRC10x0F8
1738PWM2 Minimum Fault Period0x0000.0000RWPWM2MINFLTPER0x0FC
1708PWM3 Control0x0000.0000RWPWM3CTL0x100
1713PWM3 Interrupt and Trigger Enable0x0000.0000RWPWM3INTEN0x104
1716PWM3 Raw Interrupt Status0x0000.0000ROPWM3RIS0x108
1718PWM3 Interrupt Status and Clear0x0000.0000RW1CPWM3ISC0x10C
1720PWM3 Load0x0000.0000RWPWM3LOAD0x110
1721PWM3 Counter0x0000.0000ROPWM3COUNT0x114
1722PWM3 Compare A0x0000.0000RWPWM3CMPA0x118
1723PWM3 Compare B0x0000.0000RWPWM3CMPB0x11C
1724PWM3 Generator A Control0x0000.0000RWPWM3GENA0x120
1727PWM3 Generator B Control0x0000.0000RWPWM3GENB0x124
1730PWM3 Dead-Band Control0x0000.0000RWPWM3DBCTL0x128
1731PWM3 Dead-Band Rising-Edge Delay0x0000.0000RWPWM3DBRISE0x12C
1732PWM3 Dead-Band Falling-Edge-Delay0x0000.0000RWPWM3DBFALL0x130
1733PWM3 Fault Source 00x0000.0000RWPWM3FLTSRC00x134
1735PWM3 Fault Source 10x0000.0000RWPWM3FLTSRC10x138
1738PWM3 Minimum Fault Period0x0000.0000RWPWM3MINFLTPER0x13C
1739PWM0 Fault Pin Logic Sense0x0000.0000RWPWM0FLTSEN0x800
1740PWM0 Fault Status 00x0000.0000-PWM0FLTSTAT00x804
1742PWM0 Fault Status 10x0000.0000-PWM0FLTSTAT10x808
1681June 18, 2014
Texas Instruments-Production Data
Tiva
™
TM4C1294NCPDT Microcontroller
